Schneider BMX- Series

The Schneider Electric BMX Series represents a family of high-performance, modular, and flexible programmable controllers and I/O modules. Designed for industrial automation applications, the BMX Series offers scalable solutions for controlling a wide range of processes, from simple machine automation to complex systems. The BMX Series is part of the Modicon programmable logic controller (PLC) family, known for its robustness, efficiency, and integration capabilities.

Key Features of Schneider Electric BMX Series

• Modular & Scalable
  Customizable with a variety of I/O modules, enabling flexible system configurations and scalability to meet growing automation needs.

• Wide I/O Support
  Includes digital, analog, high-speed counters, PWM outputs, and temperature inputs for versatile automation.

• Multiple Communication Protocols
  Supports Modbus TCP, Ethernet/IP, CANopen, and Profibus, with dual Ethernet ports for redundancy.

• Real-Time Diagnostics
  Built-in diagnostics for system health, fault detection, and network monitoring.

• Safety Compliant
  Meets IEC 61508 and UL standards, supporting emergency stops and fail-safe operations.

• Industrial Durability
  Operates in temperatures from 0°C to 60°C and withstands harsh conditions like humidity and vibrations.

• Flexible Programming
  Supports IEC 61131-3 languages (LD, ST, FBD, SFC, IL) for quick and easy development.

• Integration with EcoStruxure™
  Compatible with EcoStruxure™ Control Expert for seamless integration into Schneider Electric’s ecosystem.

Below are the primary product types within the BMX Series:

BMX PLCs (Programmable Logic Controllers)

These are the core control units of the BMX Series, featuring high processing power, modular design, and the ability to manage complex industrial automation systems. The BMX PLCs come with various configurations, including base units with different I/O capacities and expansion options.

• BMX P Series: Standard PLCs for general automation needs, offering powerful processing capabilities and easy integration with other systems.
• BMX X Series: Higher-performance PLCs for more demanding applications, offering additional processing power, memory, and faster communication speeds.

BMX I/O Modules

I/O modules provide the necessary interfaces to connect the PLC to various sensors, actuators, and devices in the field. These modules are designed for flexibility and expandability.

• Digital I/O Modules: For handling discrete input and output signals.
• Analog I/O Modules: For handling analog signals (e.g., temperature, pressure).
• Mixed I/O Modules: Combining both digital and analog I/O in a single module.
• High-Speed Counter Modules: For applications requiring fast counting and measurement capabilities.

BMX Communication Modules

These modules enable communication between the BMX PLC and external devices, other PLCs, or SCADA systems, supporting various industrial protocols.

• Ethernet Communication Modules: Support Ethernet/IP, Modbus TCP, and other network protocols for remote monitoring and control.
• Fieldbus Communication Modules: Support communication standards such as Profibus, CANopen, and Modbus RTU.

BMX Power Supply Modules

Power supply modules ensure that the BMX PLC and its connected modules receive the necessary power to operate efficiently and reliably. These modules typically support 24V DC input voltage.

BMX Expansion Modules

Expansion modules allow for system scalability by adding additional I/O or communication capabilities to the existing BMX PLC setup. These modules are designed to easily integrate with the base unit and increase the overall I/O capacity of the system.

BMX Safety Modules

Safety modules ensure compliance with industrial safety standards, providing features like emergency stop, fail-safe functions, and safe I/O processing for safety-critical applications.
